| Manufacturer |
Cisco Systems, Inc |
|
| Manufacturer Part Number |
Cisco ASR 1002 |
|
| Product Type |
Aggregation Service Router |
|
| Form Factor |
Desktop - modular - 3U |
|
| Connectivity Technology |
Wired |
|
| System Bandwidth |
5G |
|
| Router Processor |
Quad-core 2.13Ghz processor |
|
| Build-in Gigabit Ethernet port |
4 * SFP ports |
|
| Redundancy |
Software |
|
| Cisco ASR 1000 Series ESP |
1 ESP slot |
|
| SIP and Ethernet line card |
Integrated ASR 1000-SIP10, not upgradable |
|
| Embedded hardware-based encryption |
Up to 1.8-Gbps crypto support throughput |
|
| Rack-mounting |
19-inch |
|
| DRAM Memory |
4GB-shared across RP and SIP |
|
| Flash Memory |
8 GB |
|
| Shared port adapters |
3 SPA slots |
|
| External USB flash memory |
1-GB USB flash-memory support |
|
| Cisco QuantumFlow Processor-based platform |
Enables advanced services to operate at high speeds without the need for additional hardware or blades. |
|
| Hardware acceleration |
Features like QoS, crypto, and access control lists (ACLs) are processed in hardware. |
|
| Control and forwarding-plane separation |
Ability to scale control plane and data plane independent of each other. |
|
| expansion Card |
● 1-port OC48/STM16 POS/RPR Shared Port Adapters
● 2-port OC12/STM4 POS Shared Port Adapters
● 4-port OC-12/STM-4 POS Shared Port Adapters
● 8-port OC12/STM4 POS Shared Port Adapters
● 8-port OC-3/STM-1 POS Shared Port Adapters
● 8-port Channelized T1/E1 to DS0 Shared Port Adapter
● 1-port OC192/STM64 POS/RPR XFP Optics
● SPA-2XOC12-POS with a license to use 1 port
● SPA-4XOC3-POS-V2 with a license to use 2 ports
● 1 Port Channelized OC3/STM-1 ATM and Circuit Emulation SPA
● Cisco 1-port 10GE LAN/WAN-PHY Shared Port Adapter
● Synchronous Ethernet SPA
● 1 port OC12 STM Shared Port Adapter
● 8-port Channelized T1/E1 to DS0 Shared Port Adapter
● 1-port Channelized STM-1/OC-3c to DS0 SPA, Version 2
● 2-port Channelized T3 to DS0 Shared Port Adapter, Version 2
● Cisco 10-Port Gigabit Ethernet Shared Port Adapter
● 24 Port Channelized T1/E1/J1 ATM and Circuit Emulation SPA |
● 2-port Clear Channel T3/E3 Shared Port Adapter, Version 2
● 4-port Channelized T3 to DS0 Shared Port Adapter, Version 2
● 4-port Clear Channel T3/E3 Shared Port Adapter, Version 2
● 2-port OC48/STM16 POS/RPR Shared Port Adapters
● 1 port OC-3c/STM-1 ATM Shared Port Adapter
● 3 port OC-3c/STM-1 ATM Shared Port Adapter
● 4-port OC-3/STM-1 POS Shared Port Adapters
● Digital Signal Processor SPA
● 1-port Channelized OC12 to DS0 SPA
● Cisco 8-Port Gigabit Ethernet Shared Port Adapter
● Cisco 4 port serial SPA
● Cisco 8-Port Fast Ethernet (TX) Shared Port Adapter
● Cisco 2-Port Gigabit Ethernet Shared Port Adapter
● 4-port OC48/STM16 POS/RPR Shared Port Adapters
● Cisco 1-Port 10GE LAN-PHY Shared Port Adapter
● Cisco 5-Port Gigabit Ethernet Shared Port Adapter
● Cisco 4-Port Fast Ethernet (TX) Shared Port Adapter
● 2 Port Channelized T3/E3 ATM and Circuit Emulation SPA
|
| Embedded Services Processor |
● Cisco ASR1000 Embedded Services Processor, 10G
● ASR1K Embedded Services Processor,5Gbps,ASR1002 only
● Cisco ASR1K Embedded Services Processor,10G,Non Crypto |
|
| 1GB USB Flash Token |
MEMUSB-1024FT |
|
| Router Processor Memory |
● M-ASR1K-1001-4GB
● M-ASR1K-1001-8GB
● M-ASR1K-1001-16GB |
|
| Feature License |
● Unified Border Element - Enterprise Edition 100 Sessions
● Unified Border Element Ent, 100 Sessions, Redundancy
● Unified Border Element Ent, 500 Sessions, Redundancy
● Unified Border Element Ent, 1000 Sessions, Redundancy
● Unified Border Element - Enterprise Edition 4000 Sessions
● Unified Border Element Ent, 4000 Sessions, Redundancy
● Unified Border Element - Enterprise Edition 16000 Sessions
● Unified Border Element Ent, 16000 Sessions, Redundancy
● CGN RTU Feature License for up to 2M Sessions on ASR1000 |
● Flex. Pack Insp. Right-To-Use Feat Lic,ASR1000 Series
● Broadband Right-To-Use Feature Lic for ASR1000 Series
● DBE Base Right-To-Use Lic for Release 2.3.x and prior
● Firewall Right-To-Use Feature Lic for ASR1000 Series
● GTP add-on to Firewall RTU Feature Licence for ASR1000
● Firewall/NAT Stateful Inter-Chassis Redundancy License
● NAT64 RTU Feature License for up to 2M Sessions on ASR1000
● ASR1000 Lawful Intercept RTU
● Broadband Right-To-Use Feature Lic for ASR1000 Series
●DBE Base Right-To-Use Lic for Release 2.3.x and prior
● App Visibility and Control
● SW Redundancy Right-To-Use Feat Lic for ASR1000 Series
● Flex. Pack Insp. Right-To-Use Feat Lic,ASR1000 Series |
| License Include |
● SASR1R1-AESK9-313S
● FLASR1-FW-RTU |
● FLASR1-IPSEC-RTU |
| IOS XE Operating System |
Cisco IOS XE Software Release 2.1 |
|
