A9K-4HG-FLEX-FC

Quote | Help
Overview

The Cisco A9K-4HG-FLEX-FC is a high-capacity module designed for the ASR 9000 Series, enhancing its scalability and flexibility. It provides cutting-edge networking capabilities, ensuring top-notch performance for modern data centers and enterprise environments. This module is known for its robust build and efficient data handling capabilities, making it a reliable choice for high-demand applications.

Quick Spec

Model A9K-4HG-FLEX-FC
Series ASR 9000
Interfaces 4 x 100 Gigabit Ethernet
Supported OS Cisco IOS-XR
Form Factor Plug-in module

Product Features

  • ● High Performance: Designed for up to 400 Gbps of throughput.
  • ● Scalability: Supports extensive scaling options with various interface modules.
  • ● Flexibility: Multiple interface types support a wide range of connectivity options.
  • ● Carrier-Class Reliability: Built for carriers with stringent performance and uptime requirements.
  • ● Advanced Support: Compatible with Cisco IOS-XR for enhanced network functionalities.

Product Applications

  • ● Data Centers: Ideal for high-speed data center interconnections and cloud computing environments.
  • ● Enterprise Networks: Supports large enterprise network backbones with high traffic demands.
  • ● Service Providers: Suitable for carrier-grade applications offering reliable and scalable networking solutions.

Supported Options

Transceiver Cisco CPAK-100G-SR10
Interface Module Cisco A9K-MPA-4X10GE
Cable Cisco CAB-100G-3M

Compare to Similar Items

Model Difference
Cisco A9K-8T-B 8 x 10 Gigabit Ethernet ports
Cisco A9K-MOD80-SE Modular line card, supports up to 80 Gbps throughput
Cisco A9K-24X10GE-SE 24 x 10 Gigabit Ethernet ports, optimized for 10G connections

Get more information

For further details about the Cisco A9K-4HG-FLEX-FC, including its price and comprehensive datasheet, feel free to contact us via Live Chat or email us at Contact@huatenmax.com. Check Cisco A9K-4HG-FLEX-FC price and A9K-4HG-FLEX-FC datasheet, buy Cisco A9K-4HG-FLEX-FC ASR 9000 with the best price and fast shipping. Free Live Chat is supported.

Specification

A9K-4HG-FLEX-FC Specification

Chassis compatibility

Compatible with the Cisco ASR 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904, ASR 9010 and ASR 9006 chassis.

●  A99-4HG-FLEX-FC, A99-4HG-FLEX-SE, A99-4HG-FLEX-TR PIDs – compatible with the ASR 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904 chassis
●  A9K-4HG-FLEX-FC, A9K-4HG-FLEX-SE, A9K-4HG-FLEX-TR PIDs – compatible with the ASR 9922, ASR 9912, ASR 9910, ASR 9906, ASR 9904, ASR 9010, ASR 9006 chassis

Port density

4 QSFP28 ports capable of 40Gb and 100Gb Ethernet traffic support. 16 SFP28 ports capable of 10Gb and 25Gb Ethernet traffic support. 24 SFP+ ports capable of 10Gb Ethernet traffic support.

Ethernet
●  10-Gbps IEEE 802.3ae compliant
●  40/100-Gbps IEEE 802.3ba compliant
●  IEEE 802.x flow control
●  Full-duplex operation
●  Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets

Performance
●  100-Gbps line rate throughput per QSFP28 port
●  25-Gbps line rate throughput per SFP28 port
●  10-Gbps line rate throughput per SFP+ port

Options

Each line card is available as either a service-edge-optimized or packet-transport-optimized line card

Reliability and availability

Line card Online Insertion and Removal (OIR) support without system impact

Physical dimensions (includes ejector bracket/lever); (H x W x D); weight

ASR 9000 400GB 5th Generation Service Edge Line Card: 1.68 x 15.87 x 24.00 in.; 18.74 lb (42.67 x 403.10 x 609.60 mm; 8.50 kg)

ASR 9000 400GB 5th Generation Packet Transport Line Card: 1.68 x 15.87 x 24.00 in.; 18.74 lb (42.67 x 403.10 x 609.60 mm; 8.50 kg)

Operating temperature

41 to 104°F (5 to 40°C)

Note: Limitations may apply when using high-power optics

Operating humidity (nominal) (relative humidity)

10 to 85%

Storage temperature

–40 to 158°F (–40 to 70°C)

Storage (relative humidity)

5 to 95%

Note: Not to exceed 0.024 kg of water per kg of dry air

Operating altitude

–60 to 4000 m (up to 2000 m conforms to IEC, EN, UL, and CSA 60950 requirements)

ETSI/EN standards

Cisco ASR 9000 Series Routers are designed to meet:

●  EN300 386: Telecommunications Network Equipment (EMC)
●  ETSI 300 019 Storage Class 1.1
●  ETSI 300 019 Transportation Class 2.3
●  ETSI 300 019 Stationary Use Class 3.1
●  EN55022: Information Technology Equipment (Emissions)
●  EN55032: Multimedia Equipment (Emissions)
●  EN55024: Information Technology Equipment (Immunity)
●  EN55035: Multimedia Equipment (Immunity)
●  EN50082-1/EN-61000-6-1: Generic Immunity Standard

EMC standards

Cisco ASR 9000 Series Routers are designed to meet:

●  FCC Class A
●  ICES 003 Class A
●  AS/NZS CISPR 32 Class A
●  CISPR 22/CISPR 32 Class A
●  EN55022/EN55032 Class A
●  VCCI Class A
●  CNS-13438 Class A
●  KN32 Class A
●  IEC/EN 61000-3-2: Power Line Harmonics
●  IEC/EN 61000-3-3: Voltage Fluctuations and Flicker
●  EN50121-4 Railway applications Part 4: Emission and immunity of the signaling and telecommunications apparatus
●  EN50121-3-2 Railway applications Part 3-2: Rolling stock - Apparatus

Immunity

Cisco ASR 9000 Series Routers are designed to meet:

●  IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)
●  IEC/EN-61000-4-3: Radiated Immunity (10V/m)
●  IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)
●  IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)
●  IEC/EN-61000-4-5: Signal Ports (1kV)
●  IEC/EN-61000-4-5: Surge DC Port (1kV)
●  IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)
●  IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)
●  IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations
●  KN35

Safety

Cisco ASR 9000 Series Routers are designed to meet:

●  UL/CSA/IEC/EN 60950-1
●  IEC/EN 60825 Laser Safety
●  ACA TS001
●  AS/NZS 60950
●  FDA: Code of Federal Regulations Laser Safety

Network Equipment Building System (NEBS)

Designed to meet:

●  SR-3580: NEBS Criteria Levels (Level 3)
●  GR-1089-CORE: NEBS EMC and Safety
●  GR-63-CORE: NEBS Physical Protection
