A9K-8HG-FLEX-SE

Chassis compatibility

Compatible with the Cisco ASR 9006, ASR 9010, ASR 9904, ASR 9906, ASR 9910, ASR 9912, and ASR 9922 chassis

Port density

2 Terabit Line Card: 15 QSFP28 ports capable of 10Gb, 40Gb, and 100Gb Ethernet traffic support. 5 QSFP-DD ports capable of 10Gb, 40Gb, 100Gb, 200Gb, and 400Gb Ethernet traffic support.

0.8 Terabit Line Card: 6 QSFP28 ports capable of 10Gb, 40Gb, and 100Gb Ethernet traffic support. 2 QSFP-DD ports capable of 10Gb, 40Gb, 100Gb, 200Gb, and 400Gb Ethernet traffic support.

Ethernet

●  100-Gbps IEEE 802.3ba compliant

●  100 Gigabit Ethernet PHY monitoring

●  400-Gbos IEEE 802.3bs compliant

●  IEEE 802.x flow control

●  Full-duplex operation

●  Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets

Performance

●  100-Gbps line-rate throughput per QSFP28 port

●  400-Gbps line-rate throughput per QSFP-DD port

Options

Each line card is available as either a service-edge-optimized or packet-transport-optimized line card

Reliability and availability

Line card Online Insertion and Removal (OIR) support without system impact

Physical dimensions(includes ejector bracket/lever); (H x W x D); weight

2T Service Edge Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 24.15 lb (41.4 x 395.7 x 604.5 mm; 10.95 kg)

2T Packet Transport Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 24.15 lb (est.) (41.4 x 395.7 x 604.5 mm; 10.95 kg)

800G Service Edge Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 21.70 lb (41.4 x 395.7 x 604.5 mm; 9.84 kg)

800G Packet Transport Combo Line Card - 5th Generation: 1.63 x 15.58 x 23.80 in.; 21.70 lb (41.4 x 395.7 x 604.5 mm; 9.84 kg)

Operating temperature

41 to 104°F (5 to 40°C)

Note: Limitations may apply when using high-power optics

Operating humidity (nominal) (relative humidity)

10 to 85%

Storage temperature

–40 to 158°F (–40 to 70°C)

Storage (relative humidity)

5 to 95%

Note: Not to exceed 0.024 kg of water per kg of dry air

Operating altitude

–60 to 4000 m (up to 2000 m conforms to IEC, EN, UL, and CSA 60950 requirements)

ETSI/EN standards

Cisco ASR 9000 Series Routers are designed to meet:

●  EN300 386: Telecommunications Network Equipment (EMC)

●  ETSI 300 019 Storage Class 1.1

●  ETSI 300 019 Transportation Class 2.3

●  ETSI 300 019 Stationary Use Class 3.1

●  EN55022: Information Technology Equipment (Emissions)

●  EN55032: Multimedia Equipment (Emissions)

●  EN55024: Information Technology Equipment (Immunity)

●  EN55035: Multimedia Equipment (Immunity)

●  EN50082-1/EN-61000-6-1: Generic Immunity Standard

EMC standards

Cisco ASR 9000 Series Routers are designed to meet:

●  FCC Class A

●  ICES 003 Class A

●  AS/NZS CISPR 32 Class A

●  CISPR 22/CISPR 32 Class A

●  EN55022/EN55032 Class A

●  CCI Class A

●  CNS-13438 Class A

●  KN32 Class A

●  IEC/EN 61000-3-2: Power Line Harmonics

●  IEC/EN 61000-3-3: Voltage Fluctuations and Flicker

●  EN50121-4 Railway applications Part 4: Emission and immunity of the signaling and telecommunications apparatus

●  EN50121-3-2 Railway applications Part 3-2: Rolling stock - Apparatus

Immunity

Cisco ASR 9000 Series Routers are designed to meet:

●  IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)

●  IEC/EN-61000-4-3: Radiated Immunity (10V/m)

●  IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)

●  IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)

●  IEC/EN-61000-4-5: Signal Ports (1kV)

●  IEC/EN-61000-4-5: Surge DC Port (1kV)

●  IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)

●  IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)

●  IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations

●  KN35

Safety

Cisco ASR 9000 Series Routers are designed to meet:

●  UL/CSA/IEC/EN 60950-1

●  IEC/EN 60825 Laser Safety

●  ACA TS001

●  AS/NZS 60950

●  FDA: Code of Federal Regulations Laser Safety

Network Equipment Building Systems (NEBS)

Designed to meet:

●  SR-3580: NEBS Criteria Levels (Level 3)

●  GR-1089-CORE: NEBS EMC and Safety

●  GR-63-CORE: NEBS Physical Protection
