WS-C3850-32XS-E

Product Code

WS-C3850-32XS-E

Enclosure Type

1 RU

Feature Set

IP Services

Ports

24 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit SFP+ (uplink)

Network Module

Shipped with C3850-NM-8-10G module

RAM

4GB

Flash Memory

4GB

Dimension

Width: 17.5 in

Depth: 17.7 in

Height: 1.8 in

Models

Description

L-LIC-CTIOS-1A

1 AP Adder License for the IOS based Wireless Controller (e-delivery)

STACK-T1-50CM=

Cisco StackWise-480 50cm stacking cable for Cisco Catalyst 3850 series switch

PWR-C1-715WAC/2

Cisco 3850 Series Secondary Power Supply PWR-C1-715WAC/2 715W AC Config 1 Secondary Power Supply

PWR-C1-1100WAC/2=

Cisco 3850 Series Secondary Power Supply PWR-C1-1100WAC/2 1100W AC Config 1 Secondary Power Supply

Product Code

WS-C3850-32XS-E

WS-C3850-12XS-S

Enclosure Type

1 RU

1 RU

Feature Set

IP Services

IP Base

Ports

24 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit SFP+ (uplink)

12 x 10/100/1000 10G SFP+ Optical ports

Network Module

Shipped with C3850-NM-8-10G module

C3850-NM-4-10G (Needed to buy separately)

RAM

4GB

4GB

Flash Memory

4GB

4GB

WS-C3850-32XS-E Specification

Ports

24 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit SFP+ (uplink)

Performance

Switching capacity: 640 Gbps ¦ Stacking bandwidth: 480 Gbps

Dimensions & Weight

Width: 17.5 in

Depth: 17.7 in

Height: 1.8 in

Weight: 13.45 lbs

Environmental Parameters

Min Operating Temperature: 23 °F

Max Operating Temperature: 113 °F

Humidity Range Operating: 10 - 95% (non-condensing)

Min Storage Temperature: -40 °F

Max Storage Temperature: 158 °F

RAM

4 GB

Flash Memory

4 GB

Interface Provided

24 x 10GBase-X SFP+ ¦ 6 x 10GBase-X SFP+ uplink ¦ 1 x USB Type A ¦ 1 x management (mini-USB) Type B

1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 2 x network stack device

Miscellaneous

MTBF: 307.99 hours

Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, EN50082-1,

EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5,

FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, KCC, RoHS, FCC Part 15 A,

AS/NZS 3548 Class A, BSMI Class A, CAN/CSA C22.2 No. 60950-1, EN 60950-1 Second Edition, IEC 60950-1 Second Edition,

VCCI Class A, KN24, KN22 Class A, EN 300386, AS/NZS CISPR 22, CNS 13438, EN 55022 Class A

Software

Cisco IOS IP Services

Power

Power Device: Internal power supply

Installed Qty: 1 (installed) / 2 (max)

Power Redundancy: Optional

Power Redundancy Scheme: 1+1 (with optional power supply)

Power Provided: 715 Watt

Voltage Required: AC 120/230 V (50/60 Hz)
