  • AW555A
  • AW555A

AW555A

Overview

AW555A is the HP P2000 2TB 6G SAS 7.2K 3.5in MDL HDD for MSA series storages. HP MSA2 / MSA2000 controller enclosures and large form factor expansion enclosures accept unique HPE SAS disk drive modules with different firmware and different trays than other HPE storage arrays and Proliant servers. The disk drives have SAS interposers attached to the back which convert the native dual port SAS interface to an SCA-40 connector. While this SCA-40 connector has the same shape as a Fibre Channel (FC) connector, the drives are NOT utilizing the FC protocol. If you look closely at the interposer, the circuitry is rather simplistic and no bridge / translator chip is attached. The interposer is, more or less, acting as a signal filter and port relocator to connect to the MSA2's proprietary backplane.

Quick Spec

Table 1 shows the spec.

Part Number

AW555A

Category

StorageWorks HardDrive

Sub-Category

7.2K

Generation

SAS MSA2

Type

Hard Drive - Hot-Plug

Capacity

2TB

Interface Type

Serial Attached SCSI

Spindle Speed

7200RPM

Ports

Dual Port

Speed

6GB/s

Supported Devices

For use only in HPE StorageWorks Systems

Modular Smart Array MSA2 1040/2040/P2000 Systems only.

Supported Devices

Table 2 shows the recommended supported MSA storages.

Model

Description

E7W03A

HP MSA 1040 2Prt 10G iSCSI DC LFF Strg

E7W03A

HP MSA 1040 2Prt 10G iSCSI DC LFF Strg

C8R09A

C8R09A - HP MSA 2040 SAN Controller

C8S53A

C8S53A - HP MSA 2040 SAS Controller

M0T61A

HP MSA 2040 SAS Dual Ctl Flash Bndl

AW592B

HP P2000 G3 SAS MSA Controller

AP837B

HP P2000 G3 MSA FC/iSCSI Controller

Get more information

Do you have anyquestion aboutthe HPE AW555A

Contact us now viaLive ChatorContact@huatenmax.com.

Specification

AW555A Specification

Category

StorageWorks HardDrive

Sub-Category

7.2K

Generation

SAS MSA2

Type

Hard Drive - Hot-Plug

Capacity

2TB

Interface Type

Serial Attached SCSI

Spindle Speed

7200RPM

Ports

Dual Port

Speed

6GB/s

Supported Devices

For use only in HPE StorageWorks Systems

Modular Smart Array MSA2 1040/2040/P2000 Systems only.
