Position：Home / Products / Switches / Huawei Switches / Huawei Data Center Switches

  • CE6880-48T4Q2CQ-EI
  • CE6880-48T4Q2CQ-EI

CE6880-48T4Q2CQ-EI

Model:Huawei CE6880-48T4Q2CQ-EI
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei CE6880-48T4Q2CQ-EI is part of the CE6800 series, offering advanced switching capabilities for modern data centers. This high-performance switch is designed for scalable network environments, ensuring efficient and reliable data transmission.

Quick Spec

Switching Capacity 2.56 Tbps
Forwarding Performance 945 Mpps
Ports 48 x 10GE SFP+, 4 x 40GE QSFP+, 2 x 100GE QSFP28
Power Supply Dual hot-swappable AC/DC
Dimensions (HxWxD) 43.6 mm x 442 mm x 599 mm

Product Features

  • ● High-density 10GE switch with flexible port configurations
  • ● Advanced QoS policies for optimized network traffic management
  • ● Redundant hot-swappable components ensuring high availability
  • ● Comprehensive security features including ACLs and SSH
  • ● Energy-efficient design with reduced power consumption

Product Applications

  • ● High-performance computing (HPC) environments requiring low-latency and high-speed data transmission
  • ● Enterprise data centers needing scalable and reliable network solutions
  • ● Cloud computing infrastructures demanding flexible and efficient bandwidth management

Supported Options

Management Module HUAWEI MM223
Power Supply Module HUAWEI PSR650-56D
Fan Module HUAWEI FAN 210

Compare to Similar Items

Model Differences
Huawei CE6880-48S4Q2CQ-EI Supports SFP+ ports instead of SFP
Huawei CE6860-48T4Q2CQ-EI Lower forwarding performance at 720 Mpps
Huawei CE6850-48T6Q-H Only has 6 x 40GE QSFP+ ports without 100GE

Get more information

Contact us through Live Chat or email us at Contact@huatenmax.com for more information about the Huawei CE6880-48T4Q2CQ-EI and its pricing. Check Huawei CE6880-48T4Q2CQ-EI price and Huawei CE6880-48T4Q2CQ-EI datasheet. Buy Huawei CE6880-48T4Q2CQ-EI CE6800 series with best price and fast shipping. Free Live Chat are supported.

Specification

Huawei CE6880-48T4Q2CQ-EI Specifications

Product Brand Huawei
Model Name CE6880-48T4Q2CQ-EI
Product Series CE6800
Ports 48x 10GE TX, 4x 40GE QSFP+, 2x 100GE QSFP28
Switching Capacity 2.56 Tbps
Forwarding Performance 1440 Mpps
Latency < 1 ??s
Operating Temperature 0??C to 45??C (32??F to 113??F)
Storage Temperature -40??C to 70??C (-40??F to 158??F)
Operating Humidity 5% to 95% (non-condensing)
Power Consumption 150W
Power Supply Dual hot-swappable AC/DC
Dimensions (HxWxD) 43.6mm x 442mm x 600mm
MAC Address Table 128K
ARP Table 64K
VLAN IDs 4K
Jumbo Frames Up to 9216 bytes
IPv4 Routes 16K
IPv6 Routes 8K
QoS ACLs, traffic policing, shaping, scheduling
Security IEEE 802.1X, AAA, RADIUS, SSH
Management Web UI, CLI, SNMP, Syslog
Warranty Limited lifetime warranty
