  • XFP-LH40-196.00
  • XFP-LH40-196.00

XFP-LH40-196.00

Model:
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com1

Live Chat
Overview

The Huawei XFP-LH40-196.00 is a high-performance 10.71G optical transponder designed to offer exceptional reliability and efficiency. Operating within a wavelength of 1550nm, it supports a frequency of 196.00THz and a power range from -19dBm to 0dBm. Its compact size and use of LC/PC connectors make it an ideal solution for dense wavelength-division multiplexing (DWDM) applications.

Quick Spec

Brand Huawei
Product Name XFP-LH40-196.00
Transmission Rate 10.71G
Wavelength 1550nm
Frequency 196.00THz

Product Features

  • ● ● Supports a wide input power range from -19dBm to 0dBm
  • ● ● High-frequency stability at 196.00THz
  • ● ● Compact LC/PC connector interface
  • ● ● Optimized for DWDM applications
  • ● ● Low dispersion penalty with 800ps/nm

Product Applications

  • ● ● Long-haul optical communication systems
  • ● ● Metropolitan Area Networks (MAN)
  • ● ● High-capacity data center interconnects

Supported Options

Accessory Model
Optical Fiber Cable G657.A2
LC/PC Connector HUA-LCPC
Optical Attenuator HUA-ATT-5dB

Compare to Similar Items

Model Differences
XFP-LH40-195.90 Different frequency at 195.90THz
XFP-LH40-197.00 Different frequency at 197.00THz
XFP-LH40-C Supports a different wavelength of C-band

Get more information

For further details about the Huawei XFP-LH40-196.00, please contact us through Live Chat or email us at Contact@huatenmax.com. Check Huawei XFP-LH40-196.00 price and XFP-LH40-196.00 datasheet, buy Huawei XFP-LH40-196.00 with the best price and fast shipping. Free Live Chat support is available.

Specification

XFP-LH40-196.00 Specifications

Brand Huawei
Model XFP-LH40-196.00
Transmission Rate 10.71Gbps
Optical Transponder Range -19dBm to 0dBm
Wavelength 1550nm
Dispersion Tolerance 800ps/nm
Output Power -1dBm to 2dBm
Channel Frequency 196.00THz
Connector Type LC/PC
Protocol XFP MSA Compliant
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to 85°C
Power Supply 3.3V
Distance Capacity Up to 40km
Modulation NRZ
Application 10G Ethernet, SONET/SDH, 10G Fibre Channel
Compatibility Multi-vendor compatible
Duplex Mode Full-Duplex
MTBF 2,000,000 hours
Digital Diagnostic Monitoring Available
Dimensions 78mm x 18.4mm x 8.5mm
