Position：Home / Products / Optical Transmission Network / Huawei MSTP

  • SSR1L75S
  • SSR1L75S

SSR1L75S

Model:
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei SSR1L75S is an advanced 16xE1 Electrical Interface Switching Board designed to provide high-performance connectivity for various network infrastructures. With a 75 Ohm electrical interface, this switching board ensures reliable data transmission and seamless integration within your telecommunication setup. Ideal for demanding network environments, it enhances efficiency and scalability.

Quick Spec

Brand Huawei
Model SSR1L75S
Interface 16xE1 Electrical
Impedance 75 Ohm
Product Type Switching Board

Product Features

  • ● ● Support for 16 E1 interfaces
  • ● ● 75 Ohm electrical interface
  • ● ● High reliability and stability
  • ● ● Seamless integration into Huawei network environments
  • ● ● Enhanced data transmission efficiency

Product Applications

  • ● ● Telecommunication networks requiring high-density E1 switching
  • ● ● Data centers with demanding performance requirements
  • ● ● Large enterprises looking for reliable network interface solutions

Supported Options

Interface module HWT-IFM16
Power supply HWT-PSU75
Cooling fan HWT-CFAN100

Compare to Similar Items

Model Differences
Huawei SSR1L120S 120 Ohm interface
Huawei SSR2L75S Support for 32 E1 interfaces
Huawei SSR1L50S 50 Ohm interface

Get more information

Check Huawei SSR1L75S price and SSR1L75S datasheet, buy Huawei SSR1L75S with best price and fast shipping. Free Live Chat are supported. For further inquiries, please contact us via Live Chat or send an email to Contact@huatenmax.com.

Specification

SSR1L75S Specifications

Brand Huawei
Model SSR1L75S
Type 16xE1 Electrical Interface Switching Board
Nominal Impedance 75 Ohm
Number of Ports 16
Port Type E1
Data Rate 2.048 Mbps per port
Connector Type BNC
Input Voltage -48V DC
Power Consumption 12W
Operating Temperature -5°C to 55°C
Storage Temperature -40°C to 70°C
Humidity 5% to 95% non-condensing
Dimensions 220mm x 25mm x 130mm
MTBF 100,000 hours
Compliance ITU-T G.703, G.704
Mounting 19-inch rack mount
LED Indicators Power, Link, Activity
Cooling Passive cooling
Warranty 1 Year
Support 24x7 Technical Support
