Position：Home / Products / Optical Transmission Network / Huawei MSTP

  • SSJ2JDCU
  • SSJ2JDCU

SSJ2JDCU

Model:
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei SSJ2JDCU is a 1-Channel Dispersion Compensation Board designed for optical fiber networks. This 40km dispersion compensation board enhances signal quality by reducing signal distortion, ensuring reliable data transmission over long distances. With an LC interface and a 3dB insertion loss, it provides exceptional performance for network operators seeking efficient dispersion management solutions.

Quick Spec

Brand Huawei
Product Name SSJ2JDCU
Channel 1-Channel
Dispersion Compensation 40km
Insertion Loss 3dB
Connector Type LC

Product Features

  • ● ● Single-channel dispersion compensation
  • ● ● 40km compensation range
  • ● ● Low insertion loss of 3dB
  • ● ● LC connector for easy integration
  • ● ● Optimized for long-haul optical fiber networks

Product Applications

  • ● ● Long-haul optical fiber communication networks
  • ● ● Telecommunication networks requiring dispersion management
  • ● ● Data centers with extensive optical fiber infrastructure

Supported Options

Accessory Model
Fiber Optic Cable FOC-40KM
Patch Panel PP-8LC
Optical Add-Drop Multiplexer OADM-1C

Compare to Similar Items

Model Differences
Huawei SSJ1JDCU Compensation range of 20km, 2dB insertion loss
Huawei SSJ3JDCU Compensation range of 60km, 4dB insertion loss
Cisco CDC20-H 2-channel, 3dB insertion loss, 50km compensation

Get more information

For further information about the Huawei SSJ2JDCU and its pricing, contact us via Live Chat or email us at Contact@huatenmax.com. Check "Huawei SSJ2JDCU" price and "SSJ2JDCU datasheet", buy "Huawei SSJ2JDCU Dispersion Compensation Board" with the best price and fast shipping. Free Live Chat support is available.

Specification

SSJ2JDCU Specifications

Product Type 1-Channel Dispersion Compensation Board
Compensation Distance 40km
Optical Interface LC
Insertion Loss 3dB
Brand Huawei
Model Name SSJ2JDCU
Channels 1
Form Factor Board
Range 40km
Working Wavelength 1525nm - 1565nm
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Humidity 0% - 95% (non-condensing)
MTBF ° 1,500,000 hours
Connector Type LC/UPC
Nodes Single
Protocol Standardized
Compliance RoHS
Power Consumption ° 4W
Dimensions 100mm x 150mm x 25mm
Application Telecommunication Networks
