Overview

The Huawei TNEI150DOC00, also known as the OptiX PTN 910-F V100R005C00, is a comprehensive product documentation designed to offer detailed insights into one of Huawei's key networking solutions. This documentation provides essential information for the installation, configuration, and maintenance of the OptiX PTN 910-F, ensuring that users can maximize the device's performance and reliability in their network environments.

Quick Spec

Brand Huawei
Product Name OptiX PTN 910-F V100R005C00
Product Type Network Device Documentation
Version V100R005C00
Release Date 2023

Product Features

  • ● ● Detailed installation guides for the OptiX PTN 910-F
  • ● ● Comprehensive configuration manuals to optimize network performance
  • ● ● Maintenance and troubleshooting instructions
  • ● ● In-depth security recommendations
  • ● ● Software upgrade outlines and procedures

Product Applications

  • ● ● Enterprise network infrastructure setup and maintenance
  • ● ● Telecommunication service provider network management
  • ● ● Data center network optimization and troubleshooting

Supported Options

Accessory Model
Network Management Software NMS8700
Optical Transceiver Modules SFP-GE-SX-MM850
Power Supply Units PSU1500-DC

Compare to Similar Items

Model Differences
Huawei OptiX PTN 910-F V100R003C00 Older software version, limited feature set
Huawei OptiX PTN 950 V200R001C00 Higher capacity, larger form factor
Huawei OptiX RTN 980A Designed for microwave transmission

Get more information

For further details about the Huawei TNEI150DOC00 and its pricing, please contact us via Live Chat or email at Contact@huatenmax.com. Check 'Huawei TNEI150DOC00' price and 'TNEI150DOC00' datasheet, buy 'Huawei TNEI150DOC00 OptiX PTN 910-F series' with the best price and fast shipping. Free Live Chat is supported.

Specification

TNEI150DOC00 Specifications

Brand Huawei
Product Name OptiX PTN 910-F
Product Version V100R005C00
Product Type Documentation
Technology PTN, SDH/SONET, Ethernet
Network Topologies Supported Ring, Star, Mesh
Chassis Dimensions 442 mm x 420 mm x 44 mm (W x D x H)
Maximum Power Consumption 50 W
Operating Temperature Range -5°C to +55°C
Network Interfaces 4 x STM-1/STM-4, 16 x FE/GE SFP
Switching Capacity 80 Gbps
Software Features QoS, MPLS, OAM, Ethernet clock synchronization
Management Interface 1 x GE, 1 x RS232
Compliance Standards ITU-T G.8032, IEEE 1588 v2
Storage Temperature Range -40°C to +70°C
Humidity 5% to 95% RH (non-condensing)
Power Supply AC: 100-240 V, DC: -48 V
Redundancy Power and interface redundancy
MTBF >100,000 hours
Cooling Fanless Design
LED Indicators Power, Alarm, Link Activity
