U161SCUB2

Model:U161SCUB2 eSpace U1900 Series Unified Gateways
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

Huawei eSpace U1900 series gateways UC colution, eSpace u1910, eSpace U1930, eSpace U1960, eSpace U1980. eSpace U1900 series gateways are suited to be as core gateways in Huawei eSpace IP telephony solution and as access gateways for branch node in eSpace UC solution.

eSpace U1960 is a medium-capacity product in eSpace U1900 series which is suitable fot the medium-sized enterprises and branches less than 1,000 users. eSpace U1960 has MTU board for media resources and E1/T1 interfaces different from U1910 and U1930. Each MTU board provides 128 channels for media resources and two E1/T1 ports. Several MTU boards can be adopted according to the user capacity. CF cards can be inserted into MTU board to store voice messages. eSpace U1960 applies to medium and large-sized enterprises and supports centralized deployment where eSpace U1900 small capacity gateways can be used as access gateway in branches.

Quick Specs

Table 1 shows the Quick Specs.

Model

U161SCUB2

Part Number

03056244

Description

eSpace U1960 Switch and Control Board

Attributes

Hardware

Category

Hardware

Product Line

Unified Communications and Collaboration

Product Family

Unified Communications

Product Series

eSpace U1960(CRS V3)

UOM

PCS

Pack Weight(kg)

1.02

Pack Volume(m^3)

0.01507

Pack Dimension(D*W*H mm)

410*245*150

Net Dimension(D*W*H mm)

280*144*20

Typic Power(W)

27

Product Details

Figure 1 shows the SCU board.

the SCU board

①

indicator

②

USB port

③

Audio port

④

Wrench

⑤

Debugging serial port

⑥

Service network port

⑦

Reset button

Compare to Similar Items

Table 2 shows the comparison of U111SCUB2 and U161SCUB2.

Product Code

U111SCUB2

U161SCUB2

Part Number

03056243

03056244

Description

eSpace U1911 Switch and Control Board

eSpace U1960 Switch and Control Board

Product Line

Unified Communications and Collaboration

Unified Communications and Collaboration

Product Family

Unified Communications

Unified Communications

Product Series

eSpace U1911(CRS V3)

eSpace U1960(CRS V3)

Typic Power(W)

15

27

Get more information

Do you have any question about the U161SCUB2

Contact us now via Live Chat or Contact@huatenmax.com.

Specification

eSpace U1960 Specifications

Maximum number of users

1,000(a maximum of 192 FXS ports for analog users or 1,000 SIP users)

Terminal type

Analog phones, IP phones, video phones and soft clients

Port

72 FXO ports or 14 E1/T1 ports

Trunk protocol

SS7, R2, PRI, QSIG, SIP

Codec

G.711A/μ, G.729a/b/ab, iLBC, G.722/G.722.1/G.722.2

Number of meeting participants

A maximum of 360 meeting participants which can be allocated to 120 meeting halls (each hall can support up to 60 participants by maximum)

Built-in voice mail(optional)

30 channels concurrently
Built-in 16G SD storage card

Power supply

AC: 100 V to 240 V, 50 Hz/60 Hz
DC: –38.4 V to –60 V (typical value: –48 V)
Redundancy: 1+1 backup

Maximum power consumption

220 W (full configuration)

Dimensions (H * W * D)

Standard 19-inch 2 U subrack
86.1 mm * 442 mm * 310 mm

Weight

10 kg (full configuration)

Environment

Temperature

Storage temperature: –40° C to +70° C
Long-term operating temperature: 0° C to 45° C
Short-term operating temperature: –5° C to +55° C

Relative humidity

5% to 95% (without condensation)

Dustproof

Less than 180 mg/m³ dust in the air (Dustproof measures should be taken in the work environment)

System Reliability

99.995%

Maintainability

Remote maintenance, automatic configuration, log collection, and Daylight Saving Time (DST)

Manageability

Centralized/remote equipment management, signaling tracing, resource management, alarm management, and quick deployment
