R8Q67A

Overview

The Aruba R8Q67A is part of the Aruba Switches series, designed by the brand Aruba. This high-performance switch offers exceptional network connectivity and advanced features to meet the demands of modern IT environments.

Product Features

  • ● The Aruba R8Q67A features 24 Gigabit Ethernet ports and 4 SFP+ ports, providing flexible connectivity options for a range of devices.
  • ● With a switching capacity of up to 176 Gbps and a forwarding rate of up to 130 Mpps, this switch ensures smooth and efficient data transmission.
  • ● It supports advanced networking protocols such as VLAN, QoS, and STP, allowing for efficient traffic management.
  • ● The switch is equipped with built-in security features, including MAC-based authentication and Access Control Lists (ACLs), ensuring network security.
  • ● It offers easy and scalable management through Aruba's Network Management platform, providing centralized control and monitoring of network devices.
  • ● The Aruba R8Q67A is built with a robust and reliable design, ensuring long-lasting performance and durability.

Key Advantages

  • ● Enhanced network connectivity and performance
  • ● Advanced network management and security features
  • ● Scalable and easy-to-manage solution
  • ● Robust and reliable design for long-term use

Product Applications

  • ● Enterprise networks
  • ● Educational institutions
  • ● Small and medium-sized businesses

Configuration and Management

The Aruba R8Q67A switch can be easily configured using Aruba's intuitive web-based interface or through command-line interface (CLI) for advanced configurations. It supports various management protocols such as SNMP and SSH, enabling seamless integration into existing network infrastructures. With Aruba's Network Management platform, administrators can centrally manage and monitor multiple switches, simplifying network administration and troubleshooting processes.

Get more information

Do you have any questions about the Aruba 6200M 24G 4SFP+ Switch price?

Contact us now via Live Chat or Contact@huatenmax.com.

Specification

R8Q67A Specifications

Differentiator 24x ports 10/100/1000BASE-T Ports 4x 1G/10G SFP ports (2x LRM; 2x LRM/MACSec 256) 1x RJ-45 Console Port 1x USB-C Console Port 1x OOBM 1x USB Type-A Host port 2 field-replaceable, hot-swappable power supply slots, 1 power supply required (ordered separately) Supports PSU JL085A Switch has two fan tray slots; Switch includes one fan tray. 1 fan tray required. Optional second fan tray ordered separately. Fan trays are field replaceable and hotswappable. Each fan tray contains two fans.
Ports 24x ports 10/100/1000BASE-T Ports 4x 1G/10G SFP ports (2x LRM; 2x LRM/MACSec 256) 1x RJ-45 Console Port 1x USB-C Console Port 1x OOBM 1x USB Type-A Host port
Memory and processor CPU: Quad Core ARM Cortex™ A72 at 1.8 GHz Memory and Flash: 8 GB DDR4 16 GB eMMC
Latency 1 Gbps: 2.28 μSec 10 Gbps: 1.46 μSec
Throughput Up to 95.2 Mpps
Routing/switching capacity 128 Gbps
Stacking capabilities 8 members
Power supply name 2 field-replaceable, hotswappable power supply slots 1 minimum power supply required (ordered separately) Supports JL085A PSU
Input voltage 100V-120V/200V-240V
Power consumption 75W at 230 VAC
Product dimensions (metric) 4.39 x 44.247 x 38.38 cm
Weight 6.01 kg
