Position：Home / Products / Networking Accessories / Modules & Cards / Huawei Optical Transceivers

  • DWDM-SFPGE-1552-52
  • DWDM-SFPGE-1552-52

DWDM-SFPGE-1552-52

Model:Huawei DWDM-SFPGE-1552-52 Optical Transceiver
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei DWDM-SFPGE-1552-52 is a high-performance DWDM Optical Transceiver designed for extended reach in telecommunication networks. With eSFP form factor, this 2.5G single-mode module operates at a wavelength of 1552.52nm and supports distances up to 120km. The module is equipped with an LC connector, making it a reliable choice for demanding network environments.

Quick Spec

Brand Huawei
Model DWDM-SFPGE-1552-52
Form Factor eSFP
Wavelength 1552.52nm
Range 120km
Connector LC

Product Features

  • Supports Dense Wavelength Division Multiplexing (DWDM)
  • 2.5 Gbps data transfer rate
  • Single-mode fiber for long-distance communication up to 120km
  • Comes in an enhanced Small Form-factor Pluggable (eSFP) package
  • High stability with a wavelength of 1552.52nm

Product Applications

  • Ideal for long-distance telecommunication transmission in metropolitan area networks (MANs)
  • Suitable for enhancing bandwidth capacity in dense urban network settings
  • Useful in backbone network systems requiring high-speed data transfer over long distances

Supported Options

Accessory Model
LC Duplex Patch Cable PC-LC-1M
Fiber Optic Attenuator FOA-5DB
Cleaning Kit CK-F9

Compare to Similar Items

Model Differences
DWDM-SFPGE-1553-33 Different wavelength (1553.33nm)
DWDM-SFPGE-1548-51 Shorter distance (80km)
DWDM-SFPGE-1560-61 Higher wavelength (1560.61nm)

Get more information

For further information about the Huawei DWDM-SFPGE-1552-52 and its price, including the Huawei DWDM-SFPGE-1552-52 datasheet, contact us through Live Chat or at Contact@huatenmax.com. Check Huawei DWDM-SFPGE-1552-52 price and DWDM-SFPGE-1552-52 datasheet, buy Huawei DWDM-SFPGE-1552-52 module with the best price and fast shipping. Free Live Chat is supported.

Specification

DWDM-SFPGE-1552-52 Specifications

Brand Huawei
Model DWDM-SFPGE-1552-52
Product Type DWDM Optical Transceiver
Form Factor eSFP
Data Rate 2.5 Gbps
Wavelength 1552.52 nm
Distance 120 km
Optical Components Single-mode Module
Connector Type LC
Temperature Range -40°C to 85°C
Hot Swappable Yes
Compliance DWDM MSA
Power Consumption 1.5W
Digital Diagnostics Yes
Receiver Sensitivity -24dBm
Transmitter Power -1 to +3dBm
Bit Error Rate (BER) 1x10^(-12)
Protocols SONET, SDH, Ethernet
Warranty 1 Year
Certification CE, FCC, RoHS
