Position：Home / Products / Networking Accessories / Modules & Cards / Huawei Optical Transceivers

  • DWDM-SFPGE-1551-72
  • DWDM-SFPGE-1551-72

DWDM-SFPGE-1551-72

Model:Huawei DWDM-SFPGE-1551-72 Optical Transceiver
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei DWDM-SFPGE-1551-72 is a high-performance Dense Wavelength Division Multiplexing (DWDM) Optical Transceiver. Designed as an enhanced Small Form-factor Pluggable (eSFP) module, it supports 2.5G transmission rates over single-mode fiber. This module, operating at a wavelength of 1551.72nm, can cover distances up to 120 kilometers and uses an LC connector.

Quick Spec

Brand Huawei
Model DWDM-SFPGE-1551-72
Transmission Rate 2.5G
Wavelength 1551.72nm
Distance 120km
Connector LC

Product Features

  • Supports Dense Wavelength Division Multiplexing (DWDM)
  • Enhanced Small Form-factor Pluggable (eSFP)
  • 2.5G transmission rate over single-mode fiber
  • Operates at a wavelength of 1551.72nm
  • Transmission reach up to 120 kilometers

Product Applications

  • Long-haul telecommunications networks requiring high-capacity and long-distance optical transmission.
  • Metropolitan Area Networks (MANs) for connecting multiple locations within a city or campus.
  • Data center interconnects that need high-speed and long-distance link capability.

Supported Options

Accessory Model
Patch Cable LC-LC SMF Patch Cable
Optical Line Protection Switch OLS-2
Custom Color Coded Dust Caps DCL-1550

Compare to Similar Items

Model Difference
DWDM-SFPGE-1531-90 Operates at 1531.90nm wavelength
DWDM-SFPGE-1560-61 Operates at 1560.61nm wavelength
DWDM-SFPGE-1528-77 Operates at 1528.77nm wavelength

Get more information

For further information about the Huawei DWDM-SFPGE-1551-72 and to check the price, please contact us via Live Chat or email at Contact@huatenmax.com. Check Huawei DWDM-SFPGE-1551-72 price and DWDM-SFPGE-1551-72 datasheet, buy Huawei DWDM-SFPGE-1551-72 with best price and fast shipping. Free Live Chat are supported.

Specification

DWDM-SFPGE-1551-72 Specifications

Brand Huawei
Model Name DWDM-SFPGE-1551-72
Type DWDM Optical Transceiver
Form Factor Enhanced Small Form-Factor Pluggable (eSFP)
Data Rate 2.5 Gbps
Wavelength 1551.72 nm
Transmission Distance 120 km
Connector Type LC
Optical Components DFB
Signal Type Single-mode
Operating Temperature Range -5°C to 70°C
Storage Temperature Range -40°C to 85°C
Power Supply Voltage 3.3V
Power Consumption < 2W
Receiver Sensitivity -23 to -8 dBm
Transmission Power -1 to 4 dBm
Maximum Receiver Power -8 dBm
Dispersion Tolerance ° 1600 ps/nm
EMC Standards EN 55032
Safety Standards IEC 60825
RoHS Compliance Yes
