Position：Home / Products / Networking Accessories / Modules & Cards / Huawei Optical Transceivers

  • DWDM-SFPGE-1548-51
  • DWDM-SFPGE-1548-51

DWDM-SFPGE-1548-51

Model:Huawei DWDM-SFPGE-1548-51 Optical Transceiver
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei DWDM-SFPGE-1548-51 is a high-performance Dense Wavelength Division Multiplexing (DWDM) Optical Transceiver designed for superior network connectivity. This enhanced Small Form-factor Pluggable (eSFP) transceiver supports 2.5G data rates over long distances up to 120 km using single-mode fiber. Operating at the 1548.51nm wavelength, it ensures reliable and efficient data transmission, making it an ideal solution for high-capacity metropolitan and long-haul networks.

Quick Spec

Brand Huawei
Product Name DWDM-SFPGE-1548-51
Type DWDM Optical Transceiver
Format eSFP
Data Rate 2.5G
Fiber Type Single-mode
Wavelength 1548.51nm
Distance 120km
Connector LC

Product Features

  • High-capacity DWDM technology for efficient bandwidth utilization
  • Extended reach of up to 120 km
  • Compact eSFP form factor for scalable deployment
  • Operates at a precise 1548.51nm wavelength
  • Supports 2.5G data rate for dependable high-speed connections

Product Applications

  • Metropolitan Area Networks (MANs) requiring high data throughput
  • Long-distance telecommunication networks
  • High-capacity data centers needing reliable, long-distance connectivity

Supported Options

Accessory Model
Mounting Bracket BRKT-ESFP
Fiber Patch Cable FPC-SM-LC-5M
Dust Cover DC-SFP-LC

Compare to Similar Items

Model Differences
DWDM-SFPGE-1530-79 Different wavelength (1530.79nm)
DWDM-SFPGE-1551-72 Different wavelength (1551.72nm)
DWDM-SFPGE-1528-33 Different wavelength (1528.33nm)

Get more information

Check Huawei DWDM-SFPGE-1548-51 price and DWDM-SFPGE-1548-51 datasheet, buy Huawei DWDM-SFPGE-1548-51 with best price and fast shipping. Free Live Chat are supported. Contact us through Live Chat or Contact@huatenmax.com for further information about the product and its price.

Specification

DWDM-SFPGE-1548-51 Specifications

Brand Huawei
Product Name DWDM-SFPGE-1548-51
Form Factor eSFP (Enhanced Small Form-factor Pluggable)
Data Rate 2.5 Gbps
Wavelength 1548.51 nm
Max Distance 120 km
Optical Components DFB Laser, PIN Photodiode
Connector LC
Temperature Range 0°C to 70°C (Standard)
Transmission Media Single-mode Fiber (SMF)
Power Supply 3.3V
Max Power Consumption 1.5W
Regulatory Compliance RoHS, CE, FCC
MTBF Greater than 1,000,000 hours
Digital Diagnostic Monitoring Yes
Fiber Mode Single-mode
Compatibility IEEE 802.3ah
TX Power 0 to +5 dBm
RX Sensitivity -28 dBm
Return Loss Greater than 20 dB
Dispersion Penalty Less than 2 dB
