Overview

The Huawei DWDM-SFPGE-1546-12 is a high-performance, Dense Wavelength Division Multiplexing (DWDM) optical transceiver. Designed as an eSFP 2.5G single-mode module operating at 1546.12nm wavelength, it supports up to 120km reach, providing efficient and reliable data transmission. This module comes with an LC connector, making it a perfect fit for long-distance communication needs.

Quick Spec

Brand Huawei
Model DWDM-SFPGE-1546-12
Wavelength 1546.12nm
Data Rate 2.5G
Reach 120km
Connector LC

Product Features

  • High-density DWDM technology
  • Extended reach up to 120km
  • Low power consumption
  • Excellent reliability and stability
  • Easy integration with existing networks

Product Applications

  • Long-haul telecommunications
  • Metro Ethernet networks
  • Data Center Interconnect (DCI)

Supported Options

Accessory Model
Optical Fiber Patch Cable Huawei LC-SM-5
DWDM MUX/DEMUX Huawei MUX-16
SFP+ Adapter Huawei SFP+ADP

Compare to Similar Items

Model Difference
DWDM-SFPGE-1540-12 Wavelength: 1540.12nm
DWDM-SFPGE-1550-12 Wavelength: 1550.12nm
DWDM-SFPGE-1560-12 Wavelength: 1560.12nm

Get more information

Check Huawei DWDM-SFPGE-1546-12 price and DWDM-SFPGE-1546-12 datasheet, buy Huawei DWDM-SFPGE-1546-12 with best price and fast shipping. Free Live Chat are supported. For more detailed information about the product and pricing, please contact us through Live Chat or email us at Contact@huatenmax.com.

Specification

DWDM-SFPGE-1546-12 Specifications

Brand Huawei
Product Name DWDM-SFPGE-1546-12
Type DWDM Optical Transceiver
Module Type eSFP
Data Rate 2.5G
Mode Single-mode
Wavelength 1546.12nm
Transmission Distance 120km
Connector LC
Temperature Range -5°C to 70°C
Power Supply 3.3V
Compliance RoHS
Tx Power 0 to 4 dBm
Receiver Sensitivity -24 dBm
Extinction Ratio 9 dB
DDM/DOM Yes
Electrical Interface LC Connector
Modulation Format NRZ
MTBF More than 1,000,000 hours
Electrical Power Consumption ° 1.5W
Laser DFB Laser
