Position：Home / Products / Networking Accessories / Modules & Cards / Huawei Optical Transceivers

  • DWDM-SFPGE-1544-53
  • DWDM-SFPGE-1544-53

DWDM-SFPGE-1544-53

Model:Huawei DWDM-SFPGE-1544-53 Optical Transceiver
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

Huawei DWDM-SFPGE-1544-53 is a DWDM Optical Transceiver designed for high-speed data transmission over long distances. It features an eSFP form factor and supports 2.5G single-mode operation over 120km with an LC connector. This transceiver is ideal for telecom and enterprise networks that require reliable, high-bandwidth communication.


DWDM-SFPGE-1544-53 Product Highlights

  • 120km reach
  • 2.5G data rate
  • Single-mode fiber
  • LC connector
  • High reliability

Product Features Comparison

Feature DWDM-SFPGE-1544-53 Cisco DWDM-SFP-1544-53 Juniper DWDM-SFP-1544-53 Finisar DWDM-SFP-1544-53 Avago AFCT-5710APZ Arista SFP-10G-DW53 Brocade E1MG-LX-OM
Reach 120km 80km 80km 40km 10km 15km 10km
Data Rate 2.5G 2.5G 2.5G 2.5G 10G 10G 1G
Connector LC LC LC LC SC LC LC
Wavelength 1544.53nm 1544.53nm 1544.53nm 1544.53nm 1550nm 1530nm 1310nm
Form Factor eSFP SFP SFP SFP XFP SFP+ SFP

DWDM-SFPGE-1544-53 Product Application Scenarios

  • Long-haul telecommunications
  • Enterprise network backbones
  • Metro network deployments

Optional Add-ons

Model Description
Huawei Fiber Patch Cable Single-mode LC to LC, 3m
Huawei SFP+ Adapter Allows SFP+ usage in SFP slot
Huawei Optical Attenuator Fixed, 5dB, LC/UPC

Get More Information

Discover unbeatable prices and fast shipping for the Huawei DWDM-SFPGE-1544-53. Access the detailed DWDM-SFPGE-1544-53 datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at Contact@huatenmax.com.

Specification

DWDM-SFPGE-1544-53 Specifications
Product Type DWDM Optical Transceiver
Form Factor eSFP
Data Rate 2.5G
Optical Fiber Type Single-mode
Wavelength 1544.53nm
Reach 120km
Connector Type LC
Operating Temperature Range 0°C to 70°C
Storage Temperature Range -40°C to 85°C
Maximum Power Consumption 1.5W
DDM/DOM Support Yes
Transmission Distance 120km
Laser Type DFB
Receiver Sensitivity -24dBm
Transmit Power -2dBm to +3dBm
Protocol Compliance IEEE 802.3
Hot Swappable Yes
EMI Class 1
Warranty 1 Year
Monitoring Provided
