Overview

The Juniper SRX-CFP-100G-SR10 is a high-performance 100GE SR10 CFP Transceiver designed for multi-mode fiber (MMF) applications. With a maximum reach of 100 meters on OM3 fiber, it is ideal for high-speed data transfer and networking tasks. This transceiver is fully supported by the SRX-MIC-1X100G-CFP module, ensuring seamless integration and optimal performance in your network.

Quick Spec

Brand Juniper
Product Name SRX-CFP-100G-SR10
Form Factor CFP
Data Rate 100 Gbps
Cable Type MMF
Maximum Reach 100m on OM3
Compatibility SRX-MIC-1X100G-CFP

Product Features

  • ● High-speed 100 Gbps data rate
  • ● Compact CFP form factor
  • ● Supports multi-mode fiber (MMF)
  • ● Maximum reach of 100 meters with OM3 fiber
  • ● Seamless integration with SRX-MIC-1X100G-CFP module

Product Applications

  • ● Data center inter-connectivity requiring high-speed data transfer
  • ● Networking infrastructure for large enterprises
  • ● High-performance computing environments needing efficient data processing

Supported Options

Module SRX-MIC-1X100G-CFP
Cable MMF OM3
Transceiver SRX-CFP-100G-SR10

Compare to Similar Items

Model Differences
SRX-CFP-100G-LR4 Supports Single-mode fiber (SMF), 10 km reach
SRX-CFP-40G-SR4 40 Gbps data rate, MMF, 100m reach
SRX-QSFP-100G-SR4 QSFP form factor, 100 Gbps, 100m on OM3

Get more information

Check Juniper SRX-CFP-100G-SR10 price and SRX-CFP-100G-SR10 datasheet, buy Juniper SRX-CFP-100G-SR10 with best price and fast shipping. Free Live Chat are supported. Contact us through Live Chat or Contact@huatenmax.com for further information.

Specification

SRX-CFP-100G-SR10 Specifications

Brand Juniper
Product Name SRX-CFP-100G-SR10
Type CFP Transceiver
Data Rate 100 GE
Interface CFP
Mode MMF (Multimode Fiber)
Distance Support 100 meters
Connector Type OM3
Supported Modules SRX-MIC-1X100G-CFP
Product Form Factor Plug-in Module
Wavelength 850 nm
Power Supply 3.3V
Temperature Range 0 to 70��C
Max Power Consumption 24W
MTP/MPO Strand Count 10
Optical Receiver Sensitivity -9.5 dBm
Signal Modulation NRZ (Non-Return to Zero)
Regulatory Compliance RoHS, CE
EMI FCC Part 15 Class B
Management Interface MDIO
