  • SFPP-XGE-TDM-STM16
  • SFPP-XGE-TDM-STM16

SFPP-XGE-TDM-STM16

Model:SFPP-XGE-TDM-STM16 - Juniper Router Transceivers
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Overview

Introducing the Juniper TSoP STM16 Smart Optic in SFPP form factor, 2KM, Clear Channel, model SFPP-XGE-TDM-STM16, a cutting-edge solution designed to elevate the performance and scalability of your network infrastructure. This smart optical transceiver combines advanced TSoP technology with the convenience of the SFPP form factor, making it an ideal choice for a wide range of applications that demand high-speed data transmission over optical fiber networks.

Quick Spec

Parameter Value
Brand Juniper
Product Name TSoP STM16 Smart Optic in SFPP form factor, 2KM, Clear Channel
Model SFPP-XGE-TDM-STM16
Form Factor SFPP
Max Distance 2KM

Product Features

  • ● Advanced TSoP Technology for optimized signal integrity
  • ● Supports Clear Channel transmission for unimpeded data flows
  • ● Designed with SFPP form factor for easy installation and compatibility
  • ● Dual Fiber operation for reliable bi-directional communication
  • ● Extended operation distance up to 2 kilometers on standard optical fiber

Product Applications

This Juniper TSoP STM16 Smart Optic offers flexible and high-performance solutions for various applications, including:

  • ● Service provider networks requiring high-speed data transmission
  • ● Enterprise network backbones for seamless data connectivity
  • ● Metropolitan area networks (MANs) for connecting offices across cities

Supported Options

Accessory Model
Optical Fiber Cable OFC-2KM
Cleaning Kit CLN-KIT-01
Diagnostic Tool DIAG-T001

Compare to Similar Items

Model Differences
SFPP-XGE-TDM-STM16 N/A - Reference Model
SFPP-XGE-TDM-STM4 Lower data rate capability
SFPP-XGE-TDM-STM64 Higher data rate capability, larger form factor

Get more information

For further details about the Juniper TSoP STM16 Smart Optic and how it can transform your network infrastructure, feel welcome to contact us through our Live Chat or via Contact@huatenmax.com. Our team is prepared to assist you with additional information and pricing.

Specification

SFPP-XGE-TDM-STM16 Smart Optic in SFPP form factor, 2KM, Clear Channel Specifications

Brand Juniper
Model Name TSoP STM16 Smart Optic in SFPP form factor, 2KM, Clear Channel
Product Code SFPP-XGE-TDM-STM16
Form Factor SFPP
Transmission Speed STM16
Transmission Distance 2KM
Wavelength 850nm
Connector Type LC
Compatible Cable Multi-mode fiber (MMF)
Data Rate 2.5Gbps
Operating Temperature Range 0��C to 70��C
Power Supply +3.3V
Max Power Consumption 1W
Digital Diagnostic Monitoring (DDM) Yes
Application Clear Channel Transport
EMI/RFI Protection Yes
Hot Pluggable Yes
MTBF 1,200,000 hours
Regulatory Compliance IEC/EN 61000-4, CE, FCC
RoHS Compliance Yes
