Position：Home / Products / Networking Accessories / Modules & Cards / Huawei Optical Transceivers

  • S-SFP-FE-LH80-SM1550
  • S-SFP-FE-LH80-SM1550

S-SFP-FE-LH80-SM1550

Model:Huawei S-SFP-FE-LH80-SM1550 Optical Transceiver
HuatenMax

Expertise Builds Trust

100+ Countries

6000+ Customers/Projects

CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts

Jim Huang

+86 136 9226 0946

Contact@huatenmax.com

Live Chat
Overview

The Huawei S-SFP-FE-LH80-SM1550 is a high-performance optical transceiver designed for seamless data transmission over long distances. This eSFP, Fast Ethernet (FE) transceiver operates on a single-mode module with a wavelength of 1550nm, capable of reaching distances up to 80 kilometers. It features an LC connector, ensuring compatibility with a wide range of networking hardware.

Quick Spec

Brand Huawei
Model S-SFP-FE-LH80-SM1550
Transmission Distance 80 km
Wavelength 1550nm
Connector Type LC

Product Features

  • ● Supports transmission distance up to 80 kilometers
  • ● Operates on a single-mode fiber with 1550nm wavelength
  • ● Compatible with eSFP and Fast Ethernet modules
  • ● Equipped with LC connectors for reliable connections
  • ● High reliability for long-distance data transmissions

Product Applications

  • ● Long-distance data centers interconnect
  • ● Metropolitan Area Networks (MANs)
  • ● Telecommunications backhaul networks

Supported Options

Optical Fiber Patch Cord OC-FC-PATCH
LC Connector Cleaner LC-CLEANER-01
Transceiver Module Case TM-CASE-HUAWEI

Compare to Similar Items

Model Difference
Huawei S-SFP-FE-SM1310 Transmission distance of 20km, 1310nm wavelength
Huawei S-SFP-GE-LH40 Supports Gigabit Ethernet, 40km distance, 1550nm wavelength
Cisco GLC-FE-100LX-RGD Rugged design for industrial environments, 10km distance, 1310nm wavelength

Get more information

Check Huawei S-SFP-FE-LH80-SM1550 price and S-SFP-FE-LH80-SM1550 datasheet, buy Huawei S-SFP-FE Series with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, please contact us through Live Chat or at Contact@huatenmax.com.

Specification

S-SFP-FE-LH80-SM1550 Specifications

Brand Huawei
Model S-SFP-FE-LH80-SM1550
Product Type Optical Transceiver
Form Factor eSFP
Data Rate Fast Ethernet (FE)
Fiber Mode Single-mode
Wavelength 1550 nm
Max Distance 80 km
Connector Type LC
Tx Power 0 ~ 5 dBm
Rx Sensitivity -34 dBm
Max Input Power -6 dBm
Operating Temperature -40°C to 85°C
Storage Temperature -40°C to 85°C
Voltage Supply Range 3.3 V
Humidity 5% to 95% non-condensing
MTBF 1,000,000 hours
Compliance RoHS, CE, FCC, CLASS 1 LASER
Digital Diagnostic Monitoring (DDM) Yes
Dimensions 56.5 x 13.4 x 8.5 mm
